FR-4 单、双面板
● 12年以上工业PCB制造经验。
● 即使是1件也没有最低订单质量
● 通过UL美国和加拿大认证
● 全天候销售和技术支持
- 参数规格
- 描述说明
- 应用领域
- 文件下载
An Experienced PCB Manufacturer
MTK's been manufacturing MCPCB Boards for 18+ years. Our full feature aluminum circuit boards making capabilities and Free DFM Check allow you to get high-quality aluminum PCBs done within budget. Our printed Aluminum PCBs are widely used for LED lighting, power equipment and automotive systems.
|
Item |
PCB Production Capability |
|
Base Material |
FR |
|
Layer |
1L-2L |
|
Finished inner/outer cooper thickness |
1OZ |
|
FR thickness |
0.4-3.0mm |
|
Minimum Size |
1200mm 1layer |
|
Controlled Impedance |
±5% |
|
Outline profile |
Rout/ V-cut/ Bridge/ Stamp hole |
|
Surface treatment |
LF HASL,immersion gold,immersion siliver,OSP |
Check our core PCB
manufacturing capabilities in the following table:
|
Technical parameters and process capability of metal substarte(MCPCB) |
|
|
ITEM |
SPECIFICATION |
|
Surface |
LF HASL,immersion gold,immersion siliver,OSP |
|
Layer |
Single side,double sided Multilayer and special structure |
|
Maximum PCB size |
1190mmx600mm OR 6x1190mm |
|
PCB thickness |
0.4-3.0mm |
|
Copper Foil thickness |
H 0.5/1/2/3/4(oz) |
|
Metal Base thickness |
0.5/0.8/1.0/1.2/1.6/2.0/3.2/5.0(mm) |
|
Shaping |
Die punching/CNC Route/V-Cut |
|
Test |
100% open&short test |
|
Shaping tolerance |
Die Punching<+- 0.05mm,CNC Route<+-0.15mm,V-CUT Thick residue>+-0.15mm |
|
Hole tolerance |
+/-0.10mm |
|
Min.Hole DIameter |
Single side 0.3/Double sided PTH0.3MM |
|
Solder mask |
green/white/black/red/yellow |
|
Min.line space |
0.1 |
|
Min.letter width |
0.1 |
|
Sile screen color |
blue/white/black/red/yellow |
|
Sopecial hole |
Spot facing/cup hole/buried via hole/buried tank |
|
File format |
Gerber,Protel,PowerPCB,AutoCAD etc |
